PP Woven Sludge Geotube Dewatering Bags System Waterproof

PP Woven Sludge Geotube Dewatering Bags System Waterproof

PP Woven Geotube Dewatering Bags

waterproof Geotube Dewatering Bags

Waterproof sludge bag dewatering system

Place of Origin:

China

Brand Name:

OEM

Certification:

ISO,SGS

Model Number:

geotube

Contact Us

Request A Quote
Product Details
Type:
Geotube, Woven Knitted
Product Name:
Geotube Bag
Material:
100% Polypropylene
Product Color:
Black
Product Function:
Filtration ,Separation,Drainage, Reinforcement
SIze:
17.5cm*9.5cm*0.5cm
Certificate:
ISO9001:2008
Weight:
100-1000g/sqm
Product Width:
Customized
Design Style:
Customized
Product Description

PP Woven Geotextile Tube Geotube for Sluge China Manufacturer



Product Description



Geotextile Tube is one of the most effective components that are most usually used in protective structure of waterproof erosion. Soft mattress is covered to the places where water flows to reduce the impact energy of water flow and protect soil particles from being flown away by water flow by means of its filtration function, thus, ensuring the stability of soil mass.

PP Woven Sludge Geotube Dewatering Bags System Waterproof 0



Item Unit Testing Standard Technical Parameters
GT70X95B GT70X95
Breaking strength MD KN/m ISO 10319-2015 85 85
CD KN/m ISO 10319-2015 105 115
Elongation of break MD % ISO 10319-2015 13 13
CD % ISO 10319-2015 8 8
Sewing Tensile Strength KN/m ISO 10321-2008 70 90
Static Bursting Strength(CBR) KN GB/T 14800-2010 8 9
Equivalent hole size(O90) mm GB/T 14799-2005 0.5 0.45
Permeability(Q50) L/m2/s GB/T 15789-2005 50 35
UV-resistance (500 Hours strength retention) % ASTMD4355-2014 90 90





Feature

1. High strength, low deformation
2. Durability: steady property, not easy to resolved, air slaked and can keep the original property long term
3. Anti-erosion: anti-acid, anti-alkali, resists insects and mould
4. Permeability: could control the sieve size to retain certain permeability



PP Woven Sludge Geotube Dewatering Bags System Waterproof 1

PP Woven Sludge Geotube Dewatering Bags System Waterproof 2
