50mm-300mm Hdpe Plastic Geocell in road construction Ground Reinforcement

50mm-300mm Hdpe Plastic Geocell in road construction Ground Reinforcement

300mm plastic geocell

plastic geocell Stabilizer

Ground geocells in road construction

Place of Origin:

China

Brand Name:

OEM

Certification:

ISO certificate

Model Number:

Plastic HDPE Geocell

Contact Us

Request A Quote
Product Details
Corrosion Resistance:
Excellent Corrosion Resistance
Function:
Distributing Load, Anti-deforming, Non-skid
Thickness Of The Sheet (mm):
1.25; 1.50; 1.75
Application 2:
Retaining Wall, Dam, Railway, Highway
Application:
Outdoor, Road Base, Slope Protection,erosion Control
Peel Strength Of Welding Point:
1000~1420n/10cm
Hole:
With Hole / Without Hole
Product Description

50-300mm Stabilizer Hdpe Geocell Gravel Grid For Ground Reinforcement Manufacture Price



Hdpe Geocell Gravel Grid  Description:

Plastic HDPE geocell is three dimensional, honeycomb like structures manufactured from high density polyethylene and jointly welded by ultrasonic technique. It is flexible to fold during the transport and installation on construction site. The geocell nets will be filled with soils, granular, cements or other on-site infill materials when stretched into web structures, which has powerful and rigid confinement in the lateral and vertical sides.



Feature

1, with flexible, transport can be folded, construction can be stretched into a network, filled with soil, gravel, concrete and other loose materials, constitute a strong lateral limit and stiffness of the structure.

2, light material, wear resistance, chemical stability, light and oxygen resistance aging, acid and alkali resistance, suitable for different soil and desert and other soil conditions.
3, higher lateral restrictions and anti-slip, anti-deformation, effectively enhance the bearing capacity of the roadbed and dispersed load.
4, Different engineering needs can be met by changing the height and welding distance of geotechnical chamber.
5, flexible, small transport volume; The connection is convenient and the construction speed is fast.





Technical Parameters:
Material Properties Unit         Test Method
Cell Depth mm 75 100 150 200
Polymer Density g/cm3 0.935-0.965 ASTM D 1505
Environmental Stress Crack Resistance Hours >400 ASTM D 5397
Environmental Stress Crack Resistance Hours 6000 ASTM D 1693
Carbon Black Content % 1.5% - 2.0% ASTM D 1603
Nominal Sheet Thickness Before Texturing mm 1.27 -5%,+10% ASTM D 5199
Nominal Sheet Thickness After Texturing mm 1.52-5%,+10% ASTM D 5199
Strip Puncture Resistance N 450 ASTM D 4833
Seam Peel Strength N 1065 1420 2130 2840 EN ISO13426-1B
Seam Efficiency % 100 GRI-GS13
Nominal Expanded Cell Size (width x length) mm 320x287,475x508 etc
Nominal Expanded Panel Size (width x length) m 2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44


Applications:


1). To stable the roadbed of railway.
2). To stable the roadbed of highway.
3). To bear the load of dike or retaining wall.
4). To the imporement of shallow river way.
5). To support the pipeline and sewer.
6). For the prevention of landslide by using geocell as a heavy-duty hybrid force retaining wall.
7). To be used as independent wall, wharf and breakwater, etc.
8). For the desert, beaches and the riverbed, the river bank's regulation.



50mm-300mm Hdpe Plastic Geocell in road construction Ground Reinforcement 0
