Plastic 3D HDPE Geocell For Slope Protection Geogrid Lattice 5mm-20mm

Plastic 3D HDPE Geocell For Slope Protection Geogrid Lattice 5mm-20mm

20mm HDPE Geocell

HDPE Geocell Geogrid

20mm geocell for slope protection

Place of Origin:


Brand Name:



ISO certificate

Model Number:

Plastic HDPE Geocell

Contact Us

Request A Quote
Product Details
Hdpe Geocell Feature:
Corrosion Resistant, Oxidation Resistance, Chemical Stability, Wear-resistant
High-density Polyethylene
1.5 Or 1.6 Or 1.7mm
Surface Treatment:
Textured Smooth
Concrete Materials, Soil & Rock
Peel Strength:
With Hole / Without Hole
Product Description

3D Geogrid Lattice Height 5-20mm Price Hdpe Geocell Plastic Gravel Grid


Plastic HDPE Geocell Description:

Geocell is a new type of high strength geosynthetic material which is popular at home and abroad. It is a three-dimensional meshcell structure formed by high strength welding of reinforced HDPE sheet material.Due to engineering needs, some need to be drilled in the diaphragm.During construction, it can be stretched into a network and filled with loose materials such as soil, gravel,concrete, etc., to form a structure with strong lateral restrictions and large stiffness.


HDPE plastic honeycomb hdpe geocell gravel grid Specifications:
1.Cell depth: 50mm , 100mm , 150mm , 200mm , 250mm
2. Welding space: 330mm~1600mm
3. Thickness: 1.0mm , 1.2mm , 1.5mm , 1.8mm
4. Appearance: smooth / textured



1.It’s extractile,flexible to fold and convenient for transportation.
2.It can be filled with soil, gravel,earth,macadam and so on when being stretched into network.
3.It has light material, wear resistance, acid and alkali resistance, anti aging.
4.It is anti-skid and anti-deformation and also has a higher lateral limit, which can reduce the thickness of roadbed.



Technical Parameters:
Material Properties Unit         Test Method
Cell Depth mm 75 100 150 200
Polymer Density g/cm3 0.935-0.965 ASTM D 1505
Environmental Stress Crack Resistance Hours >400 ASTM D 5397
Environmental Stress Crack Resistance Hours 6000 ASTM D 1693
Carbon Black Content % 1.5% - 2.0% ASTM D 1603
Nominal Sheet Thickness Before Texturing mm 1.27 -5%,+10% ASTM D 5199
Nominal Sheet Thickness After Texturing mm 1.52-5%,+10% ASTM D 5199
Strip Puncture Resistance N 450 ASTM D 4833
Seam Peel Strength N 1065 1420 2130 2840 EN ISO13426-1B
Seam Efficiency % 100 GRI-GS13
Nominal Expanded Cell Size (width x length) mm 320x287,475x508 etc
Nominal Expanded Panel Size (width x length) m 2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44


It is mainly used in foundation reinforcement, soft foundation treatment, steep slope protection, landslide prevention and hybrid retaining wall subject to load and weight; especially suitable for weathered mountain forests, deserts and swamps.

1.Load support: Solve unacceptable road, parking and yard surface problems.

2.Slope protection: Create a stable environment for long-term sustainability of embankment material.
3.Channel protection: Ensure stability and protection of channels exposed to all types of erosive conditions.
4.Vegetated retaining walls: including steepened slopes, retaining walls, gravity walls and so on.
5.Shorelines: Provide unique solutions to prevent erosion problems caused by water contact, surface flow and wave action.


Plastic 3D HDPE Geocell For Slope Protection Geogrid Lattice 5mm-20mm 0



1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

2.what can you buy from us?
Geocell,Geogrid,Geomembrane,Geotextile,and other related products.

3. why should you buy from us not from other suppliers?
More than 20 years of production experience

4. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;

Professional geosynthetics manufacturer
