Steel Plastic Welding Geogrid For Road Pavement Steel Plastic Geogrid Subgrade Reinforced Bidirectional Geogridsreinforcement
Product Description
High strength steel wire (or other fibers), after special treatment, polyethylene (PE) or polypropylene (PP), and other additives, are extruded to form composite high-strength tensile strip, and the surface has rough embossing, which is the high-strength reinforced geobelt
|
Steel Plastic Composite Geogrid Technical Parameter (GB standard)
|
|||||||||
|
Item
|
Specification
|
||||||||
|
Type
|
GSZ 30-30
|
GSZ 50-50
|
GSZ 60-60
|
GSZ 70-70
|
GSZ 80-80
|
GSZ 100-100
|
GSZ 150-150
|
||
|
Vertical and horizontal ultimate tensile strength≥(KN/M)
|
30
|
50
|
60
|
70
|
80
|
100
|
150
|
||
|
Vertical and horizontal ultimate tensile strength elongation≤(%)
|
3
|
||||||||
|
Peel force of connection point≥(KN)
|
300
|
500
|
|||||||
Widely using in :
Reinforced tunnel
Railway reinforcement
Highway reinforcement
Culvert Reinforcement
Slope protection
Municipal Engineering
Foundation strengthening of parking lot
