Interlocking Geo Grid Pavers Plastic Grass Parking Grid Lightweight

Interlocking Geo Grid Pavers Plastic Grass Parking Grid Lightweight

Interlocking geo grid pavers

Grass geo grid pavers

Interlocking plastic grass parking grid

Place of Origin:

China

Brand Name:

OEM

Certification:

ISO certificate

Model Number:

HDPE Plastic Grass Grid Parking Lot Lawn Gravel Grid

Contact Us

Request A Quote
Product Details
Grid Shape:
Squareness Or Ellipseor Honeycombed
Material:
High-density Polyethylene Plastic
Connection Mode:
Lap Buckle
Height:
38mm 48mm 68mm
Usage:
Construction
Advantage:
Pressure, Wear Resistance, Impact Resistance
Feature:
Distribute Loading
Keyword:
HDPE Grass Paving Grids
Product Description

High Strength Interlocking Lightweight Plastic Grass Gravel Paver Grid



Plastic Grass Gravel Paver Grid  Product Description

Grass Grid is a lightweight plastic structure manufactured from HDPE or recycled plastics,designed to stabilize and support turf, grass or decorative gravel. Grass Grid is used in the landscape, construction and environmental remediation industries. Positioned under the grass surface, Grass Grid distributes loads from pedestrian and vehicular traffic to the base course below, minimizing grass and root compaction. The interconnected cells allow roots to develop with minimal restriction, resulting in a durable and stable grass surface.



Specification:



1) Height: 38mm,48mm,68mm

2) Size:390*410mm, 500*500mm

3)Pressure strength:200-250Tons

4) Material: HDPE

5) Color: black and green.

6)Certificates: CE, ISO9001, ISO14001.





Technical Data:

Materials
HDPE
Height
38mm
48mm
48mm
68mm
Width
500mm
500mm
500mm
500mm
Length
500mm
500mm
500mm
500mm
Edge
Jagged edge
Jagged edge
Flat edge
Flat edge
Pressure Strength
160-250 Ton / Sqm
Durability
at least 4 years in neutral ground of 4
Working Temperature
-10℃ - 50℃ (6.8℉ - 122℉ )
Anti UV
UPE>30 T ( UVA ) AV
Testing
ISO ASTM








How to install?
1. Start in corner of the project area with male tabs of first grid facing towards the center of the area
2. Line up female slots of next grid over male tabs of the first grid.
3. Lock grid into its place.
4. Repeat until the area is covered with a connected grid.
5. Gravel fill: Fill the grid with the desired aggregate to top of the grid.
6. Lightly compact to settle.
7. Grass fill: Fill the grid with soil and seed.



Features
1) Simple structure in linear type ,easy in installation and maintain.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high autoimmunization and intellectualization, no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Application

1.Grass Parking lots
2.Overflow grass car&bus parking lots
3.Grass Fire Truck Access routes/Fire lanes
4.Handicap access routes
5.Golf cart paths
6.Emergency grass access and parking spaces
7.Residential access and parking spaces
8.Grass driveway and grass shoulders.
