Composite Geomembrane With Two Layers Geotextile One Layer Geomembrane For Landfill Tailings Treatment Subway Tunnel Construction

Two Layers Geotextile Geomembrane

Subway Tunnel Construction Geomembrane

Landfill Tailings Treatment Geomembrane

Place of Origin:

China

Brand Name:

OEM

Certification:

ISO9001

Request A Quote

Composite Geomembrane With Two Layers Geotextile One Layer Geomembrane For Landfill Tailings Treatment Subway Tunnel Construction

Product Details

Function:

Anti-Leakage

Another Name:

Composite Geomembrane With Geotextile

Classification:

Composite Impervious Geomembrane

Package:

Standard Exporting Package

Peeling Strength:

6n/Cm Min (GB/T 17642-2008)

Length:

50m/100m/150m Or Customized

Width:

1m-8m

Tensile Strength:

≥17MPa

Usage:

Agriculture/Dam/Landfill/Tailing Dam

Material Types:

HDPE/LDPE

Standard:

GB/ASTM Gri-GM13

Service Life:

Least 5 Years

Surface Choices:

Smooth, Textured, Bi-Color

Uv Resistance:

≥4000h

0.3 - 2.5mm HDPE Geomembrane Dam Reservoir Mining Fish Farm Geomembrane Pond Liner

Get Best Price

Composite Geomembrane Fish Tank Lining Geomembrane Pond Liner customizable Length

Get Best Price

HDPE Plastic Waterproofing Anti-Seepage Geomembrane in Landfill Tailings Treatment

Get Best Price

Composite Geomembrane With Two Layers Geotextile One Layer Geomembrane For Landfill Tailings Treatment Subway Tunnel Construction

Get Best Price

86--18095658976

angela@zhongloo.com

86-551- 65540070

Contact Now

Product Description

Composite Geomembrane With Two Layers Geotextile One Layer Geomembrane For Landfill Tailings Treatment Subway Tunnel Construction

Composite geomembrane Description:

What is Composite Geomembrane?

The most common structure of a composite geomembrane consists of a geomembrane layer (often made of high-density polyethylene, HDPE) laminated to one or more geotextile layers. The geomembrane layer provides impermeability to fluids, while the geotextile layers enhance mechanical strength, puncture resistance, and provide protection against ultraviolet (UV) degradation and environmental factors.

Two Layers and One Film Reservoir Seepage Control Composite Geomembrane in Landfill Tailings Treatment

Composite Geomembrane Main Features:

1.Composite Geomembrane Impermeability: Composite geomembrane provide an effective barrier against the passage of liquids, gases, and contaminants. This impermeability helps to prevent pollution of soil and groundwater, making them ideal for containment applications such as landfill liners, pond liners, and liquid containment systems.

2. Composite Geomembrane Strength and Durability: The combination of geomembrane and geotextile layers in composite geomembranes enhances mechanical strength, puncture resistance, tear resistance, and durability. This ensures long-term performance and stability, even in challenging environmental conditions or when subjected to heavy loads.

3.Composite Geomembrane Chemical Resistance: Composite geomembrane exhibit excellent resistance to a wide range of chemicals, including acids, alkalis, hydrocarbons, and other aggressive substances. This chemical resistance ensures protection against corrosion and degradation, making them suitable for applications involving hazardous materials or chemical containment.

4.Composite Geomembrane Environmental Compatibility: Composite geomembrane are manufactured using materials that are inert, non-toxic, and environmentally friendly. They do not leach harmful chemicals into the surrounding soil or water, making them safe for use in sensitive environmental areas and for applications requiring compliance with environmental regulations.

Two Layers and One Film Reservoir Seepage Control Composite Geomembrane in Landfill Tailings Treatment

Composite geomembrane Products Specification

Technical Parameters of compound geomembrane
Product weight G/M2		400	500	600	700	800	900	1000
SPEC	1 layer geotextile +1 layer membrane	150/0.25	200/0.3	300/0.3	300/0.4	300/0.5	400/0.5	400/0.6
SPEC	2 layer geotextile +1 layer membrane	100/0.2/100	100/0.3/100	150/0.3/150	200/0.3/200	200/0.4/200	200/0.5/200	250/0.5/250
Breaking strength (kN/m)		5.0	7.5	10.0	12.0	14.0	16.0	18.0
Elongation at break (%)		300~100
CBR Mullen burst strength (KN)		1.1	1.5	1.9	2.2	2.5	2.8	3.0
Vertical permeability coefficient (CM/S)		K*10-11~13
Hydraulic pressure (MPa)		0.4~0.6			0.6~1.0

Composite geomembrane Application

1,Composite Geomembrane for Landscape engineering: garage top greening, roof garden, football field, golf course, beach project.
2, Composite Geomembrane for Municipal engineering: road base, subway, tunnel, landfill.
3, Composite Geomembrane for Construction engineering : upper or bottom layer of building foundation, basement wall, bedding filtration and heat insulation.
4, Composite Geomembrane for Traffic engineering: highway, railway basement, dam and slope.

Professional geosynthetics manufacturer
Anhui Zhonglu Engineer Materials Co., Ltd
Angela:86-18095658976
