HDPE High Definition Polyethylene Liner Industrial Design Style for Fish and Shrimp Farm Ponds Balck Waterproof

HDPE High Definition Polyethylene Liner Industrial Design Style for Fish and Shrimp Farm Ponds Balck Waterproof

Place of Origin:

china

Brand Name:

Zhongloo

Certification:

ISO9001/ISO14001/BV/SONCAP

Model Number:

Zl-TGM

Contact Us

Request A Quote
Product Details
Material:
HDPE, EPDM, LDPE, LLDPE
Design Style:
Modern
Application:
Fish Farm Pond Liner
Feature:
Waterproof, Anti-Corrosion, Durable
Length:
Customized
Warranty:
More Than 5 Years
Color:
Black Green White Blue
Standard:
GB/ASTM GRI-GM13
Product Description

                                                  Geomembrane Description

HDPE Geomembrane Pond Liner Circular Tanks HDPE PVC Geomembrane Dam Liner Water Tank
For Fish Farming Aquaculture

High-density polyethylene (HDPE) geomembranes provide an impermeable barrier against various solids and liquids. They feature excellent chemical and UV resistance, superior impermeability, and high yield and welded seam strengths, making them widely used as liners. Our geomembranes are available in different thicknesses, with varying prices based on thickness specifications.These geomembranes are ideal for seepage control in specialized industries and are widely applied in aquaculture, reservoirs, sewage treatment ponds, and other water containment.

HDPE High Definition Polyethylene Liner Industrial Design Style for Fish and Shrimp Farm Ponds Balck Waterproof 0

Geomembrane is a low-permeability synthetic membrane liner or barrier used with soil, rock, or other geotechnical materials to control fluid migration in a wide range of civil, environmental, and industrial applications. Made primarily from high-density polyethylene (HDPE), linear low-density polyethylene (LLDPE), or PVC, geomembranes are known for their excellent chemical resistance, durability, and flexibility

Geomembrane Feature

1. Good physical and mechanic performance.

2. High tearing resistance, strong deformation adptability.
3. Corrosion resistance, aging resistance.
4. Good adaptability to high and low temperature, non-toxicity, long service life.
5. Good waterproof, drainage, anti-seepage and damp proof effects.
6. Complete width and thickness specifications, low cost and easy installation.

HDPE High Definition Polyethylene Liner Industrial Design Style for Fish and Shrimp Farm Ponds Balck Waterproof 1

Geomembrane Characteristics:
1. Good flexibility
2. For service temperature range:-70°C~110°C
3. Corrosion resistance, aging resistance
4. Excellent environmental stress cracking resistance property
5. High tensile strength and elongation
Geomembrane Main Features:
1.UV resistance
2. Anti-seepage;
3. Isolation
4. High tearing resistance
5. Puncture-resisting

HDPE High Definition Polyethylene Liner Industrial Design Style for Fish and Shrimp Farm Ponds Balck Waterproof 2

HDPE Geomembrane Application:
(1)Aquaculture:
Using the geomembrane anti-seepage feature; geomembrane liners can be used as fish ponds, shrimp pond, tank liner and others.
(2)Landfill:
HDPE geomembrane is the most widely used in landfill anti-seepage engineering material. The use of main parts of the bottom of the landfill liner, landfill sealing cover, leachate regulating pool liner, etc.
(3)Water Treatment System :
HDPE geomembrane is applied to the adjustment of the power plant and sewage treatment plants pool;and a series of water treatment systems.
(4)Mining:
HDPE geomembrane suitable mining: washing pool, pool heap leaching, heap yard, dissolving tank, tank, storage area, the bottom line of the tailings seepage control, etc





HDPE Geomembrane pond liner Technical Parameter
ASTM Standard geomembrane
Spec
Properties
Test method
ASTM
GMS0.5
GMS0.75
GMS1.0
GMS1.25
GMS1.5
GMS2.0
GMS2.5
Thickness
D5199
0.5mm
0.75mm
1.00mm
1.25mm
1.50mm
2.00mm
2.50mm
Density (≥ g/cc)
D1505
0.940
0.940
0.940
0.940
0.940
0.940
0.940
Tensile Properties
(Each direction) (≥)
• yield strength
• break strength
• yield elongation
• break elongation
D 6693
Type IV


8 kN/m
14kN/m
12%
700%


11 kN/m
20kN/m
12%
700%


15 kN/m
27 kN/m
12%
700%


18 kN/m
33 kN/m
12%
700%


22 kN/m
40 kN/m
12%
700%


29 kN/m
53 kN/m
12%
700%


37kN/m
67kN/m
12%
700%
Tear Resistance (≥)
D 1004
64 N
93 N
125 N
156 N
187 N
249 N
311 N
Puncture Resistance (≥)
D 4833
160 N
240 N
320 N
400 N
480 N
640 N
800 N
Stress Crack Resistance (≥)
D 5397
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
500 hr.
Carbon Black Content
D 1603
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
Carbon Black Dispersion
D 5596
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Note(1)
Oxidative Induction Time (OIT) (≥)
(a)Standard OIT
- or -
(b)High Pressure OIT


D 3895

D 5885


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.
