Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects

Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects

Pond Waterproofing Geomembrane Liner

Waterproofing Geomembrane Liner

HDPE Geomembrane Liner for Landfill

Place of Origin:

China

Brand Name:

Zhongloo

Certification:

CE ISO ASTM

Model Number:

ZL-TGGS

Contact Us

Request A Quote
Product Details
Material:
HDPE LDPE LLDPE PVC PE
More Surface Treatment:
Smooth And Textured
Color Classification:
Black White Blue Green (Customized)
Thickness:
0.2-4mm
Standard:
ASTM Gri-GM13
Keyword:
HDPE Geomembrane Waterproof Liner
Product Description

      Anti-Seepage Geomembrane for Wastewater Treatment Plants, Tailings Dams, and Oil Containment



A geomembrane may sound like a medical experiment gone wrong, but its uses and applications are both varied and fascinating. Geomembranes are synthetic membrane liners or barriers used to control fluid migration in a manmade project, structure, or system. They are made from relatively thin continuous polymeric sheets that are sometimes made from the infusion of geotextiles with asphalt, elastomer, or polymer sprays. This means that their applications to geotechnical engineering and other industrial clients are endless.



Geomembranes are being used in environmental, hydraulic, transportation, and oil and gas applications as well as the waste industry. The most common type are the continuous polymeric sheets. When larger geomembranes are needed, they are thermally or chemically melted together at the seams for strength and durability. The size of the geomembrane is completely customizable, so they are can be as small as a backyard fish pond or as large as a football field if necessary.



To get a better idea of what you can use a geomembrane for, here are just some of the most common uses:

  • As liners for potable or reserve water (e.g., safe shutdown of nuclear facilities)
  • As fish pond liners
  • As liners for waste liquids (e.g., sewage sludge), radioactive or hazardous waste liquid
  • As liners for the agriculture industry
  • As liners for various waste conveyance canals
  • As liners for primary, secondary, and/or tertiary solid-waste landfills and waste piles
  • As linings for emergency spillways
  • As waterproofing liners within tunnels and pipelines
  • To contain and transport liquids in trucks
  • To contain and transport potable water and other liquids in the ocean
  • Beneath highways to prevent pollution from deicing salts
  • Beneath and adjacent to highways to capture hazardous liquid spills.

Basically, geomembranes are used wherever loss of material cannot be allowed, be that clean water, wastewater, vapor, soil, hazardous materials, or any other substance that doesn't need to escape its designated space. Because flowing, pooling, frozen, and standing liquids (and even vapors) can be so devastating if not managed properly, these geomembranes have allowed industries to continue to develop and support many more projects than previously done before.

Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 0

Anhui Zhonglu Engineer Material Co., Ltd is the leading geomembrane manufacturer, wholesaler, supplier and exporter dedicated in supplying one stop geomembrane products and solutions to worldwide customers since its foundation in 2008. We have over 200 professional staffs and 30,000 square meters manufacturing factory equipped with state of the art production lines and testing equipment.Product innovation, quality assurance and customer satisfaction are our long term commitment to our partners. Our main innovative,high quality geomembranes include Smooth Geomembrane HDPE Liner, Textured HDPE Geomembrane, Composite Geomembrane Liner, HDPE liner, pond liner, geotextile membranes and other geosynthetic products such as geotextile, geocell, geosynthetic clay Liner,geogrid and drainage board, etc al. All products had been certificated by the ISO9001, ISO14001, Soncap, SASO and BV certificates and passed the test of SGS and Intertek etc. Our professional geommebrane factory is equipped with advanced processing machines and production lines, which give us the power to keep high product quality, shorter delivery time and competitive cost to meet the demands of our worldwide customers. Most of our products had been kept up with the international forefront counterparts, some of them have enjoyed leading position, especially smooth HPDE geomembranes. We also can manufacture according to your special requirements, ODM, OEM, customization are also available. Our company had provided many types of effective and states of the art s, and other geosythetic products to over 86 countries.Our main customers are from Australia, France, Sweden, UK, Hong Kong, Hungary, New Zealand, Poland, Mexico, Ecuador, Brazil,Pakistan, Bangladesh, Thailand, Vietnam, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, India, UAE, Saudi Arabia, Qatar,Kenya, Ghana, Ethiopia, Somalia, South Africa, Swaziland, Mongolia etc. We are willing to become your partners with our high cost-performance, innovative geomembranes and geosythetic products, excellentquality and perfect after-sale service. Hope to be your partners.

Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 1

HDPE Anti-Seepage Geomembrane is a high-performance, low-permeability synthetic geomembrane liner manufactured in strict accordance with the GRI GM13 standard. This HDPE geomembrane is produced from premium virgin polyethylene resin, blended with carbon black, UV stabilizers, antioxidants, and anti-aging agents to ensure long-term durability and environmental safety.

The smooth-surfaced HDPE geomembrane delivers excellent impermeability, chemical resistance, and superior UV resistance, making it ideal for exposed applications. As a reliable geomembrane liner, it is widely applied in geotechnical and environmental engineering projects.

Typical applications of this HDPE geomembrane include:



Solid waste landfills and hazardous waste containment

Mining operations and tailings dams

Wastewater treatment facilities

Aquaculture ponds and fish farming

Water reservoirs, canals, and irrigation systems



With its outstanding geomembrane performance, this product is designed to prevent seepage, minimize environmental pollution, and maintain structural integrity over long service periods. The HDPE geomembrane is an essential material for projects requiring a durable, UV-resistant, and low-permeability lining system.

Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 2



HDPE Geomembrane Technical Parameter (GRI GM13 ASTM Standard)



Spec
Properties
Test method
ASTM
GMS0.5 GMS0.75 GMS1.0 GMS1.25 GMS1.5 GMS2.0
Thickness D5199 0.5mm 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm
Density (≥ g/cc) D1505 0.940 0.940 0.940 0.940 0.940 0.940
Tensile Properties
(Each direction) (≥)
• yield strength
• break strength
• yield elongation
• break elongation
D 6693
Type IV


8 kN/m
14kN/m
12%
700%


11 kN/m
20kN/m
12%
700%


15 kN/m
27 kN/m
12%
700%


18 kN/m
33 kN/m
12%
700%


22 kN/m
40 kN/m
12%
700%


29 kN/m
53 kN/m
12%
700%
Tear Resistance (≥) D 1004 64 N 93 N 125 N 156 N 187 N 249 N
Puncture Resistance (≥) D 4833 160 N 240 N 320 N 400 N 480 N 640 N
Stress Crack Resistance (≥) D 5397 500 hr. 500 hr. 500 hr. 500 hr. 500 hr. 500 hr.
Carbon Black Content D 1603 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0%
Carbon Black Dispersion D 5596 Note(1) Note(1) Note(1) Note(1) Note(1) Note(1)
Oxidative Induction Time (OIT) (≥)
(a)Standard OIT
- or -
(b)High Pressure OIT


D 3895

D 5885


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.


100 min.

400 min.

Product Features
1. Good physical and mechanic performance.
2. High tearing resistance, strong deformation adptability.
3. Corrosion resistance, aging resistance.
4. Good adaptability to high and low temperature, non-toxicity, long service life.
5. Good waterproof, drainage, anti-seepage and damp proof effects.
6. Complete width and thickness specifications, low cost and easy installation.
Basic Details
Geomembrane; pond liner
1.Main Thickness:0.1mm,0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,2.5mm
2.Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3.Main Length:50m/100m
4.Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6.Material:HDPE, LDPE,LLDPE
7. Certificate & Test: ISO, TUV,SGS
8. Quality Control: Third party test and factory lab test
Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 3
Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 4
Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 5
Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 6
Black HDPE Geomembrane Liner For Landfill Pond Lining And Waterproofing Projects 7
Q:Can you send samples? A:Yes,we are very happy to provide you with free samples to check the quality of our products.
Q:Are you a manufacturer or a trading company? A:Our company located in Hefei,Anhui Province,with are gistered capital of 52 miion yuan.It is a professiona lmanufacturer of geomembrane,geotextile,geogrid and other products.So we have the competitive price with best quality.
Q:Can you produce the product according to customers' requirements? A:Sure,we are professional manufacturer,OEM and ODM are both welcome.
Q:How long is the delivery time? A:General within 3-7days after received the deposit
Q:How to control product quality? A:Our factory adopts lean management,products from the beginning to the end of the production process have strict quality control.All products must be strictly tested before packing and shipping
