Aquaculture Fish Farm Waterproof Geomembrane HDPE Geomembrane Liner – Waterproof Barrier for Dam, Fish Farm, Pond, Pool, Tank

Aquaculture Fish Farm Waterproof Geomembrane Pond Liner HDPE High Density for Landfill Dam Soil Protection

HDPE Geomembrane Pond Liner is a high-strength, low-permeability synthetic liner engineered for superior containment performance. Manufactured in full compliance with GRI GM13 standards, it is produced from 100% virgin polyethylene resin blended with carbon black, antioxidants, UV stabilizers, and anti-aging additives, ensuring exceptional durability and resistance to environmental stress cracking.

With its smooth surface finish, this geomembrane is specifically designed for exposed applications that demand outstanding UV resistance, chemical stability, and water impermeability. It provides reliable long-term protection for a variety of geotechnical, agricultural, and environmental engineering projects.

Aquaculture:
1.HDPE geomembrane’s excellent anti-seepage properties make it ideal for lining fish ponds, shrimp ponds, tanks, and other aquaculture containment systems.

Landfill:
2.Widely used in landfill engineering, HDPE geomembrane serves as the primary lining material for landfill bottoms, sealing covers, leachate collection ponds, and other landfill containment structures.

Water Treatment Systems:
3.Applied in power plants and sewage treatment facilities, HDPE geomembrane is used for lining adjustment ponds and various water treatment pools to ensure effective containment and leakage prevention.

Mining:
4.Suitable for diverse mining applications, including wash ponds, heap leach pads, heap yards, dissolution tanks, storage areas, and tailings ponds, providing reliable seepage control and environmental protection.

Geomembrane Pond Liner Technical Parameter

ASTM Standard geomembrane pond liner

Characteristics:

1. Superior flexibility

2. Extreme temperature tolerance (-70°C to 110°C)

3. Chemical corrosion & aging resistance

4. Exceptional environmental stress cracking (ESC) resistance

5. High tensile strength with elongation capacity

6.

Main Features:

1. UV-resistant

2. Impermeable barrier

3. Reliable isolation

4. High tear-resistant

5. Puncture-proof

HDPE Geomembrane Application:
(1) Aquaculture:
Utilizing the geomembrane pond liner's anti-seepage properties, our geomembrane pond liner serves as:

• Fish farm

• Shrimp containment

• Tank sealing

• Recirculating aquaculture

(2) Landfill:
As the industry-standard geomembrane pond liner solution:

• Base geomembrane pond liner for landfill bottoms

• Capping geomembrane pond liner closure systems

• Leachate collection geomembrane pond liner

• Regulation pond geomembrane pond liner

(3) Water Treatment Systems:
Critical geomembrane pond liner applications include:

• Power plant cooling geomembrane pond liner

• Wastewater treatment geomembrane pond liner

• Equalization basin geomembrane pond liner

• Potable water geomembrane pond liner reservoirs

(4) Mining:
Heavy-duty geomembrane pond liner installations:

• Heap leach pad

• Tailings storage

• Process solution

• Sediment control

• Acid rock drainage containment

  Product Specification



  HDPE Geomembrane pond liner Technical Parameter

  ASTM Standard geomembrane

  Spec Properties	Test method ASTM	GMS0.5	GMS0.75	GMS1.0	GMS1.25	GMS1.5	GMS2.0	GMS2.5
  Thickness	D5199	0.5mm	0.75mm	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm
  Density (≥ g/cc)	D1505	0.940	0.940	0.940	0.940	0.940	0.940	0.940
  Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation	D 6693 Type IV	8 kN/m 14kN/m 12% 700%	11 kN/m 20kN/m 12% 700%	15 kN/m 27 kN/m 12% 700%	18 kN/m 33 kN/m 12% 700%	22 kN/m 40 kN/m 12% 700%	29 kN/m 53 kN/m 12% 700%	37kN/m 67kN/m 12% 700%
  Tear Resistance (≥)	D 1004	64 N	93 N	125 N	156 N	187 N	249 N	311 N
  Puncture Resistance (≥)	D 4833	160 N	240 N	320 N	400 N	480 N	640 N	800 N
  Stress Crack Resistance (≥)	D 5397	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.
  Carbon Black Content	D 1603	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%
  Carbon Black Dispersion	D 5596	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)
  Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT	D 3895 D 5885	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.
