Non Woven Geotextile Geosynthetic Clay Layer GCL Liner For Golf Course Pond

Non Woven Geotextile Geosynthetic Clay Layer GCL Liner For Golf Course Pond

Non Woven geosynthetic clay layer

Pond geosynthetic clay layer

Non Woven gcl liner

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Anti-leakage Projects
Product Name:
Bentonite Composite Waterproof Blanket
Black White
Sodium Bentonite, Special Composite Geotextile And Non-woven Fabric
Water Conservancy, Garbage Landfills, Underground
Normal 30m
1m-6m.Normal 5.8m
4 Kg/m2 - 6 Kg/m2
Product Description

Geosynthetic Clay Liner Bentonite Non Woven Geotextile And Pp Woven Cloth Composite GCL For Golf Course Pond

Product Description:
Bentonite waterproof blanket
Waterproof blanket, bentonite composite waterproof blanket (GCL) is made of graded natural sodium-based bentonite particles, by the needle punching process and equipment, the bentonite particles fixed in Geotextile and plastic woven fabric and made of blanket waterproofing roll material. Bentonite waterproof blanket has excellent waterproofing (seepage) performance.


Technical Parameters:


Bentonite composite waterproof blanket
item Specification
Unit area weight≥(g/㎡) ≥4000 ≥4000 ≥4000
Bentonite Swelling Index≥(mL/2g) 24 24 24
Blue absorption≥(g/100g) 30 30 30
Tensile Strength≥(N/100mm) 600 700 600
Maximum elongation≥(%) 10 10 8
Peel strength of non-woven fabric and woven fabric≥(N/100m) 40 40 _
Peel strength of pe film and non-woven fabric
_ 30 _
permeability coefficient≤(m/s) 5.0*10^-11 5.0*10^-12 5.0*10^-12
Durability of bentonite/≥(mL/2g) 20 20 20



Product Features:

Has excellent waterproof and impermeable properties, impermeable hydrostatic pressure up to 1.0MPa or more, permeability 5x10-11m / s, unit area bentonite quality 5kg/m2, bentonite is a natural inorganic material, will not be aging reaction, good durability; and will not cause any adverse impact on the environment, is an environmentally friendly material.


The width of the product can reach 6 meters, which matches the international specifications of geotextile (membrane) and greatly improves the construction efficiency.

Non Woven Geotextile Geosynthetic Clay Layer GCL Liner For Golf Course Pond 0



Q:Can you send samples?

A:Yes,we are very happy to provide you with free samples to check the quality of our products.
Q:Are you a manufacturer or a trading company?
A:Our company located in Hefei,Anhui Province,with are gistered capital of 52 miion yuan.It is a professiona lmanufacturer of geomembrane,geotextile,geogrid and other products.So we have the competitive price with best quality.
Q:Can you produce the product according to customers' requirements?
A:Sure,we are professional manufacturer,OEM and ODM are both welcome.
