Place of Origin:
China
Brand Name:
Zhongloo
Certification:
CE/ISO
Model Number:
100gsm-1000gsm
Contact Us
River Filtration Non-Woven PP Long Fiber Filament Non-Woven Geotextile
Product Description:
Filament fibers are arranged into reticular through different equipment and technology. Then through the acupuncture craft, let different fibers interwoven with each other, mutual entanglement, fixed and make the fabric standardizing. This is in order to make the fabric soft, plump, thick, stiff and achieve different thickness to meet the using requirements. In addition, its relative product is short fiber geotextile fabric, but the tensile strength of the filament is higher than that of the short fiber.
Product Paraments:
| Filament spunbond needle punched non-woven geotextile | |||||||||
| item | Specification | ||||||||
| 100 | 200 | 250 | 300 | 400 | 500 | 600 | 800 | 1000 | |
| The quality deviation per unitarea(%) | -5 | ||||||||
| Thickness(mm ≥) | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 4.5 | 6.8 |
| Width deviation(%) | -0.5 | ||||||||
| Breaking strength(KN/M≥) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
| Breaking elongation(%) | 40-80 | ||||||||
| CBR Bursting strength(KN≥) | 0.80 | 1.60 | 1.90 | 2.90 | 3.90 | 5.30 | 6.40 | 7.90 | 8.50 |
| Vertical and horizontal tear strength(KN/M) | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 |
| Vertical permeability coefficient(cm/s) | K*(0.001~0.01) Ps: k=1.0-9.9 | ||||||||
Application:
