Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m

Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m

50m geotextile drainage membrane

4m geotextile drainage membrane

Drainage geotextile 4m 50m

Place of Origin:

China

Brand Name:

Zhongloo

Certification:

CE/ISO

Model Number:

100gsm-1000gsm

Contact Us

Request A Quote
Product Details
Product Name:
Drainage Fabric Polyester Or Polypropylene Woven Or Nonwoven Geotextile
Project Solution Capability:
Total Solution For Projects
After-sale Service:
Online Technical Support
TypeNon Woven PP/PET Geotextile:
PP & PET
Certificate:
ISO9001:2008
Function:
Anti-seepage
Geotextile Type:
Non-Woven Geotextiles
Design Style:
Farmhouse
Product Description

Drainage Fabric Polyester Or Polypropylene Woven Or Nonwoven Geotextile



Product Description:



Polyester reinforced nonwoven fabric non-woven fabric has the characteristics of high strength, high extension and puncture resistance.
As the reinforcement of asphalt waterproof material, it is widely used in the construction industry.
The function of the reinforcement material in the waterproof membrane is mainly to increase the tensile strength of the waterproof membrane. Secondly, with this kind "skeleton", the membrane can be made thicker and more stable.



Product Paraments:



Filament spunbond needle punched non-woven geotextile
item Specification
100 200 250 300 400 500 600 800 1000
The quality deviation per unitarea(%) -5
Thickness(mm ≥) 0.8 1.2 1.6 2.2 2.8 3.4 4.2 4.5 6.8
Width deviation(%) -0.5
Breaking strength(KN/M≥) 4.5 7.5 10 15 20 25 30 40 50
Breaking elongation(%) 40-80
CBR Bursting strength(KN≥) 0.80 1.60 1.90 2.90 3.90 5.30 6.40 7.90 8.50
Vertical and horizontal tear strength(KN/M) 0.14 0.21 0.28 0.42 0.56 0.70 0.82 1.10 1.25
Vertical permeability coefficient(cm/s) K*(0.001~0.01) Ps: k=1.0-9.9



Application:

Main Function
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 0
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 1
Transmission
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 2
Separation
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 3
Filtration
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 4
Cushion
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 5
Drainage
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 6
Reinforcement
1. Stabilization In stabilization, the fabric is applied on top of a material that is highly compressible. Most often, this material is wet, soft soil. Here, the geotextile allows water to seep from the soft soil to draining material. As a result, it consolidates the basement layer, thus strengthening it and making it a more trustworthy base.
2. Separation Fabric is laid between two layers of different materials, such as two different soil types, new construction, and soil, or new and old pavement. Separation is sometimes used interchangeably with stabilization, but there are fine distinctions.
3. Filtration Using geotextile infiltration is similar to using in stabilization. The main aim in both cases is to allow the passage of water from the covered layer. The goal of this application is to remove water while preventing soil and or any other fine particles from passing through. This is achieved in combination with a filter behind the geotextile. In this process, water is removed, rather than being filtered into a different material.
4. Moisture Barrier This application is almost the direct opposite of the above applications. In the moisture barrier, the geotextile is used to block water rather than allowing water to pass through. This is accomplished by applying an asphaltic suspension. As a result, the fabric becomes impermeable and suitable for use in construction projects such as pavement rehabilitation.
5. Drainage Geotextile material can help gather water or gas and then transport it along its plane, therefore providing seamless transmission. This process is what is traditionally called drainage function, which can be highly effective in chimney drains as well as drip drains.
6. Reinforcement In reinforcement, the geotextile acts as a source of strength instead of strengthening the bottom layer like in stabilization.
Polyester Polypropylene Woven Geotextile Drainage Membrane 4m 50m 7
