Polyester PP Woven Geotextile Fabric For Horse Arena 250g/M2

Polyester PP Woven Geotextile Fabric For Horse Arena 250g/M2

Horse Arena pp woven geotextile

pp woven geotextile Fabric

250g/M2 geotextile fabric for horse arena

Place of Origin:

China

Brand Name:

Zhongloo

Certification:

CE/ISO

Model Number:

100gsm-1000gsm

Contact Us

Request A Quote
Product Details
Product Name:
Black Color Polyester Pp Geotextile Geofabric Prices 250g/M2
Project Solution Capability:
Total Solution For Projects
After-sale Service:
Online Technical Support
Model No.:
Nonwoven Geotextile Fabric
Sample:
Available
Function:
Anti-seepage
Geotextile Type:
Non-Woven Geotextiles
Unit Weight:
80GSM-1000GSM
Product Description

Black Color Polyester Pp Geotextile Geofabric Prices 250g/M2



Product Description:



Zhongloo has been one of the leading geotextile manufacturers and suppliers in the industry for more than two decades. Our sales and service network caters to all our valuable clients with the right solution.

The Geotextile fabric is specially designed to be used in ground engineering and drainage applications due to its excellent filtration mechanism. In addition, geotextiles make a fine choice in designing and construction work due to their quick installation and easy handling process.

Product Paraments:

Staple fiber needle punched non-woven geotextile
item Specification
Vertical and horizontal fracture strength(KN/M) 3 5 8 10 15 20 25 30 40
Elongation corresponding to standard breaking strength (%) 20-100
CBR Bursting strength(KN) 0.6 1 1.4 1.8 2.5 3.2 4 5.5 7
Deviation rate of weight per unit area(%) ±5
Vertical and horizontal tearing strength(KN) 0.10 0.15 0.20 0.25 0.40 0.50 0.65 0.80 1.00
Width deviation rate(%) -0.5
Thickness deviation rate(%) ±10
Vertical permeability coefficient(cm/s) k*(0.001-0.1) Ps: k=1.0-9.9
Acid and alkali resistance(% ≥) 80
Antioxidant performance(% ≥) 80
UV resistance (% ≥) 80



They are widely used in the following applications:

Applications:

  • Road works
  • Ground stabilization
  • Drainage and filtration systems
  • Construction works
  • Waste disposal sites and water purifying plants
  • Hydraulic marine works
  • Coastal protection
  1. Non-woven geotextile fabric is used in revetments to prevent erosion and retain backfill materials. The geotag non-woven geotextile is an arrangement of fibres like polypropylene or polyester either oriented or randomly patterned in a sheet, resembling felt, and with the help of the needle punching technology, it then creates a strong pliable textile with excellent elongation properties.
  2. The needle punching helps protect geotextile from delamination when exposed to wear and tear. Geotag non-woven geotextiles are only intended to be permeable to water and air so that they can pass through them without being obstructed. They are able to withstand both wet and dry conditions, and they do not decompose or are not attacked by fungus. These geotextiles are resistant to soil acid, alkalis, and most chemicals. Geotag non-woven geotextiles comprise a variety of thicknesses, weights, and forms, and each has its own special function.
  3. Woven geotextile is used in many civil engineering and building applications. Polypropylene or polyester strip fibre undergoes a special weaving process during the manufacturing stage. Geotag woven geotextile has high strength in both directions while having very low elongation.
  4. The weight ratio of woven geotextile is capable of resisting UV rays, soil chemicals, mildew, and insects. Geotag woven geotextile is an excellent separator and ideal for road installation, building projects, and embankment construction.Geotag woven geotextile is highly recommended for road construction because it enhances the durability of paved and unpaved areas. Geotag woven geotextiles are primarily used for separation, reinforcement, and filtration.
Polyester PP Woven Geotextile Fabric For Horse Arena 250g/M2 0
