Long Fiber Filament Needle Punched Geotextile For Highway Subgrade

Long Fiber Filament Needle Punched Geotextile For Highway Subgrade

Needle Punched Geotextile Geogrid

Long Fiber Filament Needle Punched Geotextile

Highway Subgrade Needle Punched Geotextile

Place of Origin:

China

Brand Name:

OEM

Certification:

ISO certificate

Model Number:

geotextile

Contact Us

Request A Quote
Product Details
Feature:
Corrosion Resistant, Wear-resistant
Packing:
Woven Plastic Bag
Usage:
Insulation, Waterproof, Water Filter
Model NO.:
Geotextile Manufacturer
Transport Package:
Woven Geotextile +Paper Rolls
Installation Location:
Highway,Railway,Dam,Coastal,Beach For Reinforcemen
Product Description



Product Description
This type of geotextile material is a Continuous filament. Non woven Geotextiles Products as protection, filtration, or separation layer alternative to diverse terrain such as soil, rock, sand, and so on. Also can be treated by UV Resistance, Thermal Bonded, Color Custom-made, etc.

Property
1. High strength, good creep property, excellent erosion resistance , aging resistance and heat resistance
2. Separation , filtration, drainage, reinforcement, protection, and maintenance function

Application
1. Filtration of soils in drainage applications by retaining soil particles while allowing for the free flow of water
2. Separation and stabilization in road and railway construction
3. Prevention of soil movement in erosion control measures
4. Cushioning and protection in many containment projects

Polyester Non-Woven Geotextile Geotextile Fabric

Product Features

1)anti-aging, the product has very high anti-ultraviolet radiation ability, not easy to degradation.

2) High temperature resistance to up to 230ºC maintaining structure stability and original physical properties.
3) High flat drainage and vertical permeability.
4) High creep resistance.
5) Resistance of erosion of chemicals in soil as well as the corrosion of gasoline and diesel etc.
6) High elongation under certain stress, thus able to adapt to uneven and irregular bases.
Polyester Non-Woven Geotextile Geotextile Fabric

Technical Parameter

Non-woven Geotextile Technical Parameter (GB standard)
Item
unit
Standard Specification
100
150
200
250
300
350
400
450
Thickness≥
mm
0.9
1.3
1.7
2.1
2.4
2.7
3
3.3
width Deciation
%
0.5
Breaking strength
KN/M
2.50
4.50
6.50
8.00
9.50
11.00
12.50
14.00
Breaking Elongation
%
25-100
Weight Tolerance
g/m²
-8
-8
-8
-8
-7
-7
-7
-7
CBR Tear Strength≥
KN
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
Tear Strength≥
KN
0.08
0.12
0.16
0.2
0.24
0.28
0.33
0.38
Vertical Permeability
N/5cm
Kx(10-¹-10-³)
EOS 090
mm
0.07-0.2

Applications of Geotextiles

1. Reinforcement effect: Used in rock engineering such as highways, railways, airports, stone dams, slope embankments, retaining walls, and embankments, to disperse soil stress, increase soil modulus, limit soil slip, and improve stability.

2. Protection function: prevent the embankment from being washed away by wind, waves, tides, and rain, and use it for bank protection, slope protection, bottom protection, and soil erosion prevention.

3. Reverse filtration: Used as a filter layer for embankments, dams, rivers, and coastal rocks, soil slopes, and retaining walls, to prevent sand particles from passing through and allow water or air to pass freely.

Polyester Non-Woven Geotextile Geotextile FabricPolyester Non-Woven Geotextile Geotextile Fabric
FAQ



Q1: Are you a factory or trading company? Where is your company located?
A1: We are a manufacturer/factory. Our company is located in Shandong, China.

Q2: How do you ensure the quality?
A2: We are working with three QC processes to guarantee the quality:
1 .For raw materials;
2.Onsite inspection during production;
3.Final QC test for each batch of finished products.
Q3: OEM OR ODM accepted?
A3: We can produce the geotextile as per customer's technical requirements.

Q4:How to get the sample?
A4: We can provide you samples for quality inspection. According to our company policy, samples are free,
we only charge the freight fee. The freight fee will be returned If you place the order.
Q5: What's your MOQ? Can I order small quantity for testing at first order?
A5: For new client, we accept small order for building mutual trust and long-term business relationship.
Q6: How many days will samples be finished? And how about the mass production?
A6: Generally prompt delivery for samples. The leading time of mass production will depend on the quantity.
Q7: What's the payment method you accept?
A7: T/T, L/C,D/P etc.
Q8: Can I visit your company?
A8: Welcome to visit our factory and it is our great pleasure.
