Place of Origin:
China
Brand Name:
zhongloo
Certification:
ISO,SGS
Model Number:
geotextile
Contact Us
Product Description
This geotextile can be made of polypropylene (PP), or polyester (PET), Polyvinyl or synthetic fiber on needle punch machine.
The mass is available from 100gsm/m² to 1500gsm/m² and the width available from 2.0m-8m, monolayer or multilayer (reinforcement geotextiles), long fiber or short fiber.
Color: All kinds of color are available.
The annual production ability is 10 million square meters.
The fabric can also be heat treated by infrared at customer's requirements. Our geotextile are UV stabilized to give protection against aging under exposure to natural ultra-violet light.
| Product Name | Fiber Geotextile |
| Material | PET |
| Width | 1m-6m or follow customers' demand |
| Length | 50m/roll,100m/roll,150m/roll or follow your request |
| Color | White |
| Certification | ISO9001:2008,CE |
| Standard | GB/T 17639-2008 |
Product Parameters
|
Non-woven Geotextile Technical Parameter (GB standard)
|
|||||||||
|
Item
|
unit
|
Standard Specification
|
|||||||
|
100
|
150
|
200
|
250
|
300
|
350
|
400
|
450
|
||
|
Thickness≥
|
mm
|
0.9
|
1.3
|
1.7
|
2.1
|
2.4
|
2.7
|
3
|
3.3
|
|
width Deciation
|
%
|
0.5
|
|||||||
|
Breaking strength
|
KN/M
|
2.50
|
4.50
|
6.50
|
8.00
|
9.50
|
11.00
|
12.50
|
14.00
|
|
Breaking Elongation
|
%
|
25-100
|
|||||||
|
Weight Tolerance
|
g/m²
|
-8
|
-8
|
-8
|
-8
|
-7
|
-7
|
-7
|
-7
|
|
CBR Tear Strength≥
|
KN
|
0.3
|
0.6
|
0.9
|
1.2
|
1.5
|
1.8
|
2.1
|
2.4
|
|
Tear Strength≥
|
KN
|
0.08
|
0.12
|
0.16
|
0.2
|
0.24
|
0.28
|
0.33
|
0.38
|
|
Vertical Permeability
|
N/5cm
|
Kx(10-¹-10-³)
|
|||||||
|
EOS 090
|
mm
|
0.07-0.2
|
|||||||
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q:Is the quality of your products stable?
The company has a complete QC system, and each batch of products will be sampled and the samples will be kept for 5 years.
Q:Can you do OEM?
A:Yes, of course. We can produce the products as per your request.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 10-15 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance,balance before shipment.
If you have another question, please feel free to contact us at any time.
