Bentonite Geosynthetics Clay Liner Waterproofing Gcl

Bentonite Geosynthetics Clay Liner Waterproofing Gcl

Place of Origin:

China

Brand Name:

zhongloo

Model Number:

FST

Contact Us

Request A Quote
Product Details
Model Number:
ZL-FST
Product Name:
Bentonite Geosynthetic Clay Liner
Usage:
Waterproof Projects
Free Sample:
Available
Color:
White
Application:
Landfill
Product Description

Bentonite Geosynthetics Clay Liner Waterproofing Gcl

Product Description

Filled between specially made composite geotextiles and non-woven fabrics with high expansion sodium based bentonite, the bentonite anti-seepage pad made by needle punching method can form many small fiber spaces, preventing bentonite particles from flowing in one direction. When encountering water, a uniform and high-density adhesive like waterproof layer is formed inside the pad, effectively preventing water leakage.





Technical Data:


No.

Item

Value





GCL-NP

Standard

1

GCL swell index, mL/2g

≥24

JG/T 193-2006

2

Methylene blue index, g/100g

≥30

JG/T 193-2006

3

Tensile strength, N/100mm

≥600

JG/T 193-2006

4

Elongation at break, %

≥10

JG/T 193-2006

5

Peel strength between non-woven geotextile and woven geotextile, N/100mm

≥40

JG/T 193-2006

6

Water permeability, m/s

≤5.0x10-11

JG/T 193-2006

7

Hydrostatic preserve

0.4MPa,1h,no leakage

JG/T 193-2006

8

Fluid loss,mL

≤18

JG/T 193-2006

9

GCL durability, mL/2g

≥20

JG/T 193-2006



Features Bentonite Mat Clay Liners
1. Improved leakage performance
2. Permanent waterproof performance
3. Simple construction and short time limit for a project.
4. Not influenced by air temperature.
5. A kind of green material and good to environmental protection.
6. More versatile than compacted clay
7. Increased airspace and liner efficiency
