Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering

Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering

Place of Origin:

CHINA

Brand Name:

zhongloo

Certification:

ISO,SGS,CE

Model Number:

geotextile

Contact Us

Request A Quote
Product Details
Model NO.:
Geotextile
Product Length:
As Request
Transport Package:
Export Package, As Request
Product Origin:
CHINA
Trademark:
Zhongloo
HS Code:
5602290000
Production Capacity:
Within 3 Days Per 40′hc
Material:
PP/Pet
Fiber:
Short Fiber And Long Fiber/Long Fiber
Kind:
Non-woven
Product Description

Product Description



1. The isolation effect:
Take geotextile separate different soil structure, make it not fluctuating interface, let each layer structure separately, in
accordance with the requirements play their performance and the overall effect.
2.Protective effect:
Geotextile can in soil or water protection and buffer effect.
3.anti-seepage effect:
Geotextile composite geotechnical material collocation, can avoid liquid leakage, gases and vapors, ensure the safety of the
environment and buildings.
Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering 0Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering 1
Specification unit 100g 200g 300g 400g 500g 600g 700g
unit weight variation % ± 6
Grab strength MD
N
≥450 ≥900 ≥1200 ≥1600 ≥2000 ≥2400 ≥3200
TD ≥450 ≥900 ≥1200 ≥1600 ≥2000 ≥2400 ≥3200

Trapezoidal tear strength
MD
N

≥170

≥350

≥420

≥500

≥580

≥660

≥900

TD
≥170 ≥350 ≥420 ≥500 ≥580 ≥660 ≥900
CBR mullen brust strength kN ≥1.3 ≥2.5 ≥3.5 ≥4.3 ≥5.5 ≥6.5 ≥9.0
breaking strength MD kN/m ≥5.0 ≥11 ≥16 ≥22 ≥28 ≥35 ≥48
TD ≥5.0 ≥11 ≥16 ≥22 ≥28 ≥35 ≥48
Elongation at break MD % 40~70 50~80 70±20
TD
puncture resistance N ≥210 ≥430 ≥650 ≥900 ≥1200 ≥1500 ≥2500



Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering 2Factory PP Long or short fibers Nonwoven needle punched Polyester Geotextile Non woven Geotextile for road covering 3

Product Application

1. Road Work
Geotextiles are widely used in the construction of the road. It reinforces the soil by adding tensile strength to it. It is used as a rapid de-watering layer in the roadbed, the geotextiles need to preserve its permeability without losing its separating functions.


2. Railway Works



The woven fabrics or the non-woven ones are used to separate the soil from the sub-soil without impeding the groundwater circulation where the ground is unstable. Enveloping individual layers with fabric prevents the material from wandering off sideways due to shocks and vibrations from running trains.



3. Agriculture

It is used for mud control. For the improvement of muddy paths and trails those used by cattle or light traffic, nonwoven fabrics are used and are folded by overlapping to include the pipe or a mass of grit.



4. Drainage

The use of geotextiles to filter the soil and a more or less single size granular material to transport water is increasingly seen as a technically and commerc
