ODM HDPE Dimpled Drainage Membrane Board For Urban Landscaping Project

ODM HDPE Dimpled Drainage Membrane Board For Urban Landscaping Project

ODM Dimpled Drainage Membrane

Landscaping Dimpled Drainage Membrane

Landscaping hdpe dimple board

Place of Origin:

China

Brand Name:

zhongloo

Certification:

CE/ISO9001/ISO14001

Model Number:

Drainage Board

Contact Us

Request A Quote
Product Details
Type:
Drainage Board
Color:
Black White Green
Certificate:
CE/ISO9001/ISO14001
Material:
HDPE
Width:
2m Or 3m
Dimple Height:
0.8mm-2.0mm
Size:
500*500*40mm/50mm/70mm
Application:
Park Road Dam Layer
Product Description



HDPE Dimple Drainge Board For Urban Landscaping Project



Product Description
The plastic drainage board is made of polystyrene (HIPS) or polyethylene (HDPE) as raw materials. The plastic bottom plate is stamped into the convex points (or hollow cylindrical porous) of conical protrusions or stiffeners. After continuous innovation and research, the raw materials have been greatly improved and changed. Now it is pressed with polyvinyl chloride (PVC) as raw materials. The compressive strength and overall flatness have been greatly improved, with a width of 1 ~ 3M, The length is 4 ~ 10 meters or more.

Drainage board have a flat back which is pressed against an underground structure such as a basement wall or subsurface footing. The pressure of backfilled soils holds the Drainage board in place. A filtration geotextile covers the drainage core. The geotextile allows unrestricted flow of moisture into the core while it restricts the passing of soil particles which could contaminate and clog the core. Since most of the soil exposed surface of a subsurface structure is covered with the Drainage board, hydrostatic pressure is virtually eliminated. Drainage board are very ligthweight, easy to handle and easy to install. They require no special equipment or skilled labor.



ODM HDPE Dimpled Drainage Membrane Board For Urban Landscaping Project 0


Technical Parameters


Plastic drainage board
item Specification
Tension at 10% elongation (N/100mm) ≥ 350
Maximum pulling force (N/100mm) ≥ 600
Elongation at break /% ≥ 25
Tear performance/N ≥ 100
Compression performance Maximum strength when compression rate is 20%/KPa ≥ 150
Extreme compression performance No break
Low temperature flexibility -10℃ no cracks
Heat aging Tensile retention at 10% elongation≥ 80
Maximum tensile retention rate/(N/100mm) /% ≥ 90
Elongation at break retention rate /% ≥ 70
Maximum strength retention rate when the compression rate is 20% ≥ 90
Extreme compression performance No break
Low temperature flexibility -10℃ no cracks
Longitudinal water flow (test pressure 150KPa) (cm²/s) ≥ 10


Drainage board Specification:

1. Raw material:HDPE

2. Dimple heigt: 8mm-20mm

3. Sheet thickness:0.8mm-2.0mm

4. Roll width: 2m or 3m

5. Length: According to user's requirements.


Drainage board Application:
Greening project: garage roof greening, roof garden, vertical greening, sloping roof greening, football field, golf course.
Municipal engineering: airport, road subgrade, subway, tunnel, landfill.
Construction engineering: the upper or lower layer of the building foundation, the indoor and outdoor walls and bottom plates of the basement, as well as the roof, roof anti-seepage and heat insulation layer, etc.
Water conservancy projects: anti-seepage water in reservoirs, reservoirs, and artificial lakes.
Traffic engineering: highway, railway subgrade, dam and slope protection layerODM HDPE Dimpled Drainage Membrane Board For Urban Landscaping Project 1


FAQ
1. What's your MOQ?
A: Our MOQ is usually 1000sqm per color.

2. What's your delivery time?
A: It's about 14 days after we received the deposit.

3. What's your payment terms?
A: TT (TT 30% as deposit,and 70% balance payment at sight of BL copy)or L/C at sight.
