10 - 50mm Height Roof Garden Drainage Board Anti Seepage

50mm Height Dimpled Drainage Membrane

Anti Seepage Roof Drainage Board

HDPE Roof Garden Drainage Board

Place of Origin:

China

Brand Name:

zhongloo

Model Number:

PSB

Request A Quote

10 - 50mm Height Roof Garden Drainage Board Anti Seepage

Product Details

Product Name:

Drainage Board

Material:

HDPE

Application:

Roof

Color:

Black Green

Height:

10~50mm

Function:

Anti-seepage

Dimpled Drainage Membrane Greening Project PVC Perforated Dimple Drainage Board Groundwork Water Solution Water Solution

Get Best Price

HDPE Drainage Board Dimple Membrane Drain Mat

Get Best Price

HDPE Drainage Boards For Construction Projects

Get Best Price

HDPE Drainage Board Dimple Sheet For Waterproofing In Roof Garden

Get Best Price

86--18095658976

angela@zhongloo.com

86-551- 65540070

Contact Now

Product Description

10~50mm Dimple Height Roof Garden Drainage Board

Product Deacription

The bottom plate of the drainage board is made of HIPS and HDPE, which can resist long-term high pressure. There will be no deformation. This long-term compression resistance can not only withstand the weight and load of the concrete floor, but also withstand the external pressure and impact force that cannot be avoided during the construction period, such as vehicles, workers and concrete pouring impulse. Keep the bottom plate out of deformation for a long time, so as to maintain the original displacement. The filter layer soil fabric on the bottom plate is used to ensure that the drainage channel is not blocked by foreign matter, such as backfill soil particles or concrete.

Technical specification

Plastic drainage board
item		Specification
Tension at 10% elongation (N/100mm) ≥		350
Maximum pulling force (N/100mm) ≥		600
Elongation at break /% ≥		25
Tear performance/N ≥		100
Compression performance	Maximum strength when compression rate is 20%/KPa ≥	150
	Extreme compression performance	No break
Low temperature flexibility		-10℃ no cracks
Heat aging	Tensile retention at 10% elongation≥	80
	Maximum tensile retention rate/(N/100mm) /% ≥	90
	Elongation at break retention rate /% ≥	70
	Maximum strength retention rate when the compression rate is 20% ≥	90
	Extreme compression performance	No break
	Low temperature flexibility	-10℃ no cracks
Longitudinal water flow (test pressure 150KPa) (cm²/s) ≥		10

Product Usages

1. Forest Park engineering: garage roof greening, roof garden, roof greening, football field, golf course, bathing beach engineering, etc.

2. Municipal works: road subgrade, subway tunnel.

3. Construction engineering: upper or lower layer of building foundation, internal and external walls of basement, seepage prevention and heat insulation layer of roof, etc. 4. Traffic engineering: road, railway subgrade, embankment and slope protection layer, etc.
